Gewicht: 75,1 g (inclusief kabels)
âMotorformaat: 35,3 x 30 mm
Schachtmaat: 5,0 * 47,5 mm
'Statordiameter: 28 mm
Statorhoogte: 8 mm
Motorsteun: 19 * 25 mm (M3 * 4)
âConfiguratie: 12N14P
âKV-waarde: 1100KV, 1400KV, 1700KV of aangepaste KV
Het volgende is een inleiding tot de D3530EVO motor met vaste vleugels. Ik hoop u te helpen de D3530EVO motor met vaste vleugels beter te begrijpen. Welkom nieuwe en oude klanten om met ons samen te blijven werken om samen een betere toekomst te creëren!
â Adviesprijs: US $ 27,99
âGrootte: 23X12.6X27.0mm
âGewicht: 20 g ± 10 g (zonder servohoorn)
âVersnelling: stalen tandwielen
âBedrijfssnelheid: 0.106sec/60° @6.0V
0,085 sec/60° bij 7,4 V
0,074 sec/60° @8,4V
Kraamkoppel: 8,0 kg-cm/111 oz-in @6,0 V
9,50 kg-cm/ 131 oz-in @7,4 V
11,0 kg-cm/ 152 oz-in @8,4 V
âMotortype: kernloze motor
âSignaaltype: digitale besturing
Materiaal behuizing: CNC AL6061 aluminium behuizing
Kabellengte connector: 180 mm JR-stekker
â Adviesprijs: US $ 27,99
âGrootte: 23X12.6X27.0mm
âGewicht: 22 g ± 3 g (zonder servohoorn)
âVersnelling: stalen tandwielen
âBedrijfssnelheid: 0.106sec/60° @6.0V
0,085 sec/60° bij 7,4 V
0,074 sec/60° @8,4V
Kraamkoppel: 8,0 kg-cm/111 oz-in @6,0 V
9,50 kg-cm/ 131 oz-in @7,4 V
11,0 kg-cm/ 152 oz-in @8,4 V
âMotortype: kernloze motor
âSignaaltype: digitale besturing
Materiaal behuizing: CNC AL6061 aluminium behuizing
Kabellengte connector: 180 mm JR-stekker
âMotor: kernloze motor
âWerkfrequentie: 1520μs / 330hz
Bedrijfsspanning: DC6.0~7.4 V
âBedrijfstemperatuurbereik: -10 tot + 60°c
âBedrijfssnelheid (6.0V): 0.07sec/60 °
âBedrijfssnelheid (7,4 V): 0,05 sec/60°
Stall Torque (6.0V): 4.8kg.cm (67.09oz/in)
Stall Torque (7.4V): 6.2kg.cm (86.81oz/in)
âPotentiometeraandrijving: directe aandrijving
âAfmetingen: 23X12X27,6 mm
Gewicht: 20,3 g (0,72 oz)
â Adviesprijs: US $ 76,80
âAfmetingen: 40x20x40,50 mm
âGewicht: 80 g ± 10 g (zonder servohoorn)
âVersnelling: Spiraalvormige stalen tandwielen
âBedrijfssnelheid: 0,12 sec/60° @8,4V
0,09 sec/60° bij 11,1 V
0,08 sec/60° bij 12,6 V
Blokkeerkoppel: 35,0 kg-cm/500 oz-in @8,4 V
45,0 kg-cm/ 583 oz-in @11,1 V
50,0 kg-cm/ 666 oz-in @12,6 V
âMotortype: borstelloze motor
âSignaaltype: digitale besturing
Materiaal behuizing: CNC AL6061 aluminium behuizing
Kabellengte connector: 300 mm JR-stekker
â Adviesprijs: US $ 76,80
âAfmetingen: 40x20x40,50 mm
âGewicht: 80 g ± 10 g (zonder servohoorn)
âVersnelling: Spiraalvormige stalen tandwielen
âBedrijfssnelheid: 0.153sec/60° @7.4V
0,10 sec/60° bij 11,1 V
0,075 sec/60° bij 14,8 V
Blokkeerkoppel: 35,0 kg-cm/500 oz-in @7,4 V
50,0 kg-cm/ 583 oz-in @11,1 V
60,0 kg-cm/ 666 oz-in @14,8 V
âMotortype: borstelloze motor
âSignaaltype: digitale besturing
Materiaal behuizing: CNC AL6061 aluminium behuizing
Kabellengte connector: 300 mm JR-stekker
