H600 -helikoptermotor
Kv: 550kV
Max Current: 60a
Max Power: 3000W
Idle stroom: 2.05A
Weerstand: 0,0241Ω
As: 6 mm
Gewicht: 347G
Voorgestelde ESC: 120A
Lipo: 3-12s
Connector: 5 mm mannelijke connector
Motor Kv | Motor Kv | 550 tpm/v |
Geen laadstroom | Idle stroom (IO/10V) | 2.05A |
Lithium Battery Life | Lipo -cel | 3-12S |
Motorgewicht | Gewicht | 378G |
Maximale continue stroom | Max continu stroom | 60A |
Maximaal continu vermogen | Max Continuous Power | 3000W |
Maximale piekstroom | Max piekstroom | 80A (2seconden) |
Maximaal piekvermogen | Max Peak Power | 4000W (2seconden) |
Aantal gokpalen | Configu-ration | 12n/10p |
Motor interne weerstand | Motorweerstand (RM) | 0,0241o |
Statordiameter | Statordiameter | 35 mm |
Statordikte | Statorhoogte | 38 mm |
Motorische diameter | Motorische diameter | 44,6 mm |
Diameter van de uitgangsas | Schachtdiameter | 6 mm |
Motorlengte | Motorlengte | 59,5 mm |
Algemene aslengte | Totale schachtlengte | 95 mm |
Installatiegatafstand | Boutgaten afstand | 30/25 mm |
Installatiegat specificaties | Boutdraad | M3 |
plug | Aansluiting | 5 mm |
Motorhoek | Motortiming | 5deg |
Drivefrequentie | Drivefrequentie | 8 kHz |
Verbinding:
